Working power supply: external DC24V (a few lamps are 12V).
Output voltage: consistent with the working power supply.
Number of channels: 4 channels.
External trigger voltage: effective trigger voltage DC7-36V.
Operating environment: Window7 or Window10.
Total output current: each channel can output 2A independently, and the current is not shared.
Brightness control method: APP software control under Window, serial communication control.
Brightness level: 0-255, a total of 255 levels of brightness can be adjusted.
External trigger interface: active trigger, high and low level trigger can be switched.
Flash mode: 0-9999ms pulse width brightness, which can be controlled by panel or serial communication. The external trigger adopts high-speed optical coupler isolation design to provide accurate and high reliability trigger signal to prevent false triggering caused by external environment jitter. Advantages: It provides power-off saving function, has high power, high response speed, high stability, high flash brightness consistency, small size, and can be placed in the distribution box.
